Broadened Horizons

Lifepo4 Battery & Charger Kit - 12V 3Ah

Lifepo4 Battery & Charger Kit - 12V 3Ah

Regular price $185.00 USD
Regular price Sale price $185.00 USD
Sale Sold out
Shipping calculated at checkout.

Pull in the big ones with this 14V Rechargeable Lithium Iron Phosphate (Lifepo4) Battery. High 3000mAh Capacity in a package slightly bigger than a pack of cigarettes means this battery is extremely power dense yet Lifepo4 is the safest, most stable Lithium technology. High Discharge provides the ability to utilize the maximum torque your motorized reel is capable of generating when you need it most to pull in the big ones.

Expected life of 5-10 year+ or 1000+ recharge cycles. Store at 40%-60% charge. Storage conditions and recharge habits can drastically impact life.

For Use with

  • PowerGrip Orthosis
  • M-Pow-R Motorized Fishing Reel - connect with 6' 5.5x2.1 Female to Male Extension Cable and place inside MpowR Waist Bag

Includes

  • 12v 3000mah Lifepo4 Battery
  • 12v Lifepo4 Charger

Battery Specifications:

  • Voltage: 12 VDC (10V - 14.6V)
  • Capacity: 3000 mAh
  • Case Type: Blue PVC Pack
  • Charge Connector: DC Barrel Plug (5.5/2.1mm)
  • Discharge Connector: Anderson Powerpole (15/30/45A compatible)
  • Maximum Continuous Discharge Current: 7A
  • Maximum Peak Pulse Current: 14A (for 2 sec.)
  • Max Power Delivered to Load at 12V: 84 Watts
  • Dimensions: 3.0 in. x 1.6 in. x 2.8 in. (75 mm x 39 mm x 72 mm)
  • Battery Weight 14 oz or 0.87 lbs. (0.4 kg)
  • Charger Weight 12 oz or 0.75lb (0.34kg)
  • Manufactures Warranty: 2 Years

Built-in PCM (protection circuit module) provides

  • internal cell balancing and management
  • protection from overcurrent, Undervoltage (over-discharge), overvoltage and short-circuiting
  • integrated charging circuitry

*This battery should be charged using a LiFePO4 compatible charger, and not a charger for SLA batteries.

Battery has No EMI/RFI (Electromagnetic Interference/Radio-Frequency Interference)

Charger Specifications

  • Input: 110-220 VAC 50 Hz - USA-style 2-prong plug
  • Output: 14.6 VDC 2A - 2.1x5.5 coaxial male plug
  • Intelligent Lithium-Iron Phosphate Battery Charging Logic

User Manual - PDF

Material Safety Data Sheet

Policy - Return/Exchange within 30 Days

Materials

Shipping & Returns

Dimensions

Care Instructions

Charge overnight. Disconnect in morning. Will fully recharge in 1.5-3 hours. NEVER leave connected to charger in storage. To extend battery life, after a day of fishing, do not recharge until the night before your next day of fishing. Store over winter at ~40%-60% charge.
